Vantec UGT-PC330GNA 2-Port 10G Network PCIe Card with Intel X550-AT Chip
Couldn't load pickup availability
Ready to work out of the box!
All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!
Ask an expert!
Vantec UGT-PC330GNA 2-Port 10G Network PCIe Card with Intel X550-AT Chip
The Vantec UGT-PC330GNA is a high-speed dual-port 10GbE network interface card designed to add two high-performance Ethernet connections to compatible desktop computers, workstations and servers. Powered by the Intel X550-AT chipset, the card provides dual RJ45 10GBASE-T ports while supporting multiple network speeds including 10Gbps, 5Gbps, 2.5Gbps, 1Gbps and 100Mbps for flexible integration with existing network infrastructure. Using a PCI Express 3.0 x4 interface, it delivers high-bandwidth connectivity for demanding networking, server, workstation, storage and multi-network applications. Additional features include support for jumbo frames up to 9K, VLAN tagging, Energy Efficient Ethernet, full-duplex operation and flow control. A low-profile bracket is included for installation in compatible compact systems.
Key Features
- Dual-port 10 Gigabit Ethernet PCIe network adapter
- Intel X550-AT network controller chipset
- Two RJ45 10GBASE-T Ethernet ports
- Supports 10Gbps, 5Gbps, 2.5Gbps, 1Gbps and 100Mbps network speeds
- PCI Express 3.0 x4 host interface
- Can be installed in compatible PCIe x4, x8 or x16 slots
- Supports jumbo frames up to 9K
- 802.1Q VLAN support
- 802.3az Energy Efficient Ethernet support
- Full-duplex operation at supported speeds
- Flow control with send/receive pause frame support
- Low-profile bracket included
- Suitable for servers, workstations and multi-network systems
- Ideal for high-speed file transfers, network storage and bandwidth-intensive applications
Specifications
| Brand | Vantec |
| Product Type | 10GbE PCIe Network Interface Card |
| Model / SKU | UGT-PC330GNA |
| Network Controller | Intel X550-AT |
| Number of Ports | 2 |
| Port Type | RJ45 10GBASE-T |
| Maximum Network Speed | 10Gbps per port |
| Supported Network Speeds | 10Gbps / 5Gbps / 2.5Gbps / 1Gbps / 100Mbps |
| Bus Interface | PCI Express 3.0 x4 |
| PCIe Slot Compatibility | PCIe x4, x8 or x16 slots |
| Ethernet Standard | 10GBASE-T |
| Jumbo Frames | Up to 9K |
| VLAN | 802.1Q VLAN Support |
| Energy Efficient Ethernet | 802.3az EEE |
| Duplex Mode | Full Duplex |
| Flow Control | Send / Receive Pause Frames |
| Bracket | Low-Profile Bracket Included |
| Dimensions | 135 x 18 x 120 mm |
| Weight | Approx. 100g |
| Windows Support | Windows 7, Windows 8.1, Windows 10 and Windows Server 2008 R2 / 2012 |
| Linux Support | Linux Kernel 2.6.24 or later |
| Virtualisation Support | VMware ESXi 5.x / 6.0 |
| Applications | Servers, Workstations, Network Storage and Multi-Network Systems |
| Included Accessories | PCIe Network Card, Low-Profile Bracket, Driver CD and Quick Installation Guide |
