Synology RackStation RS2423RP+ 12-Bay Rackmount NAS - AMD Ryzen V1780B Quad-Core, 8GB RAM
Couldn't load pickup availability
Ready to work out of the box!
All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!
Ask an expert!
Synology RackStation RS2423RP+II 12-Bay Rackmount NAS
The Synology RackStation RS2423RP+II is a 2U 12-bay rackmount NAS designed for centralized business storage, file sharing, backup, surveillance and demanding data-management applications. Powered by an AMD Ryzen V1780B quad-core processor and equipped with 8GB DDR4 ECC memory, it provides enterprise-oriented connectivity with dual 1GbE ports, a 10GbE RJ-45 port and redundant hot-swappable power supplies.
Key Features
- 12-bay 2U rackmount NAS
- AMD Ryzen V1780B quad-core processor
- 4 cores and 8 threads
- Up to 3.6GHz turbo frequency
- 8GB DDR4 ECC UDIMM installed
- Memory expandable up to 32GB
- Supports 3.5-inch SATA HDDs and 2.5-inch SATA SSDs
- 12 hot-swappable drive bays
- Expandable to 24 drive bays with a compatible expansion unit
- 1 × 10GbE RJ-45 network port
- 2 × 1GbE RJ-45 network ports
- 2 × USB 3.2 Gen 1 ports
- PCIe Gen3 x8 expansion slot with x4 link
- Redundant hot-swappable power supplies
- Supports Synology High Availability
- Supports SHR, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6 and RAID 10
- Designed for business file management, backup, synchronization and surveillance
- Drives not included
Specifications
| Brand | Synology |
|---|---|
| Product Family | RackStation |
| Product Type | Rackmount NAS Enclosure |
| SKU | RS2423RP+II |
| Form Factor | 2U |
| Drive Bays | 12 |
| Drive Type | 3.5-inch SATA HDD / 2.5-inch SATA SSD |
| Hot-Swappable Drives | Yes |
| Processor | AMD Ryzen V1780B |
| CPU Cores | 4 |
| CPU Threads | 8 |
| Base Frequency | 3.35GHz |
| Turbo Frequency | 3.6GHz |
| System Memory | 8GB DDR4 ECC UDIMM |
| Maximum Memory | 32GB |
| 10GbE | 1 × RJ-45 |
| 1GbE | 2 × RJ-45 |
| USB | 2 × USB 3.2 Gen 1 |
| Expansion Port | 1 × Mini-SAS HD |
| PCIe | 1 × Gen3 x8 slot, x4 link |
| Maximum Drive Bays | 24 with compatible expansion unit |
| RAID | SHR, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Maximum Single Volume | Up to 200TB with 32GB RAM |
| Dimensions | 88 × 482 × 578mm |
| Weight | 11.9kg |
| Rack Support | 4-post 19-inch rack |
| Power Supply | Redundant hot-swappable power supplies |
| Operating Temperature | 0–35°C |
| Storage Temperature | -20–60°C |
| Drives Included | No |
