Synology RackStation RS1626xs+ 16-Bay NAS Server with Intel Xeon CPU
Couldn't load pickup availability
Ready to work out of the box!
All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!
Ask an expert!
Synology RackStation RS1626xs+ 4-Bay Rackmount NAS
The Synology RackStation RS1626xs+ is a compact 1U rackmount NAS designed for demanding business storage, file services, collaboration, backup and virtualization workloads. It features an Intel Xeon D-1726 6-core processor, 16GB DDR4 ECC RDIMM memory, dual 10GbE networking and two integrated M.2 NVMe slots for SSD caching. The system can be expanded from four internal drive bays to up to 16 bays using a compatible expansion unit.
Key Features
- 4-bay 1U rackmount NAS
- Expandable to 16 drive bays
- Intel Xeon D-1726 6-core processor
- 12 threads with up to 3.5GHz turbo frequency
- 16GB DDR4 ECC RDIMM installed
- Memory expandable up to 64GB
- Supports 3.5-inch SATA HDDs and 2.5-inch SATA SSDs
- 2 × M.2 2280 NVMe SSD slots
- 2 × 10GbE RJ-45 network ports
- Dedicated out-of-band management LAN port
- 2 × USB 3.2 Gen 1 ports
- PCIe Gen4 x8 expansion slot
- Supports optional 10GbE, 25GbE and Fibre Channel expansion
- Designed for enterprise file services, backup, collaboration and virtualization
- Powered by Synology DiskStation Manager (DSM)
- Drives sold separately
Specifications
| Brand | Synology |
|---|---|
| Product Family | RackStation |
| Product Type | Rackmount NAS |
| SKU | RS1626xs+ |
| Form Factor | 1U |
| Internal Drive Bays | 4 |
| Maximum Drive Bays | 16 with compatible expansion unit |
| Compatible Drives | 3.5-inch SATA HDD / 2.5-inch SATA SSD |
| M.2 Slots | 2 × M.2 2280 NVMe |
| Processor | Intel Xeon D-1726 |
| CPU Cores | 6 |
| CPU Threads | 12 |
| Base Frequency | 2.9GHz |
| Turbo Frequency | 3.5GHz |
| Memory | 16GB DDR4 ECC RDIMM |
| Maximum Memory | 64GB |
| 10GbE | 2 × RJ-45 |
| Management Port | 1 × Out-of-Band Management LAN |
| USB | 2 × USB 3.2 Gen 1 |
| PCIe | 1 × Gen4 x8 slot |
| Expansion Port | 1 × Mini-SAS HD |
| Supported RAID | RAID F1, Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| SSD Cache | 2 × M.2 NVMe |
| Dimensions | 44 × 481.9 × 668.5mm |
| Weight | 9.5kg |
| Rack Support | 4-post 19-inch rack |
| Drives Included | No |
